Category

Product	Model	Motor Holding Torque(N.m)	Current(A)	Reduction Ratio	Matched driver
Planetary NEMA17(42mm)	42HSPG33A415	0.2	1.5	4,5,10,16,20,25,40,50,100	JB415M
Planetary NEMA17(42mm)	42HSPG38A415	0.4	1.5	4,5,10,16,20,25,40,50,100	JB415M
Planetary NEMA17(42mm)	42HSPG47A415	0.6	1.5	4,5,10,16,20,25,40,50,100	JB415M
Planetary NEMA17(42mm)	42HSPG60A415	0.8	1.5	4,5,10,16,20,25,40,50,100	JB415M
Planetary NEMA23(57mm)	57HSPG41A430	0.6	3.0	4,5,10,16,20,25,40,50,100	JB542C
Planetary NEMA23(57mm)	57HSPG51A430	1.0	3.0	4,5,10,16,20,25,40,50,100	JB542C
Planetary NEMA23(57mm)	57HSPG56A430	1.3	3.0	4,5,10,16,20,25,40,50,100	JB542C
Planetary NEMA23(57mm)	57HSPG76A440	2.3	4.0	4,5,10,16,20,25,40,50,100	JB542C
Planetary NEMA23(57mm)	57HSPG85A440	2.6	4.0	4,5,10,16,20,25,40,50,100	JB542C
Planetary NEMA23(57mm)	57HSPG115A440	3.5	4.0	4,5,10,16,20,25,40,50,100	JB542C
Planetary NEMA34(86mm)	86HSPG65A442	3.3	4.2	4,5,10,16,20,25,40,50,100	JB860C
Planetary NEMA34(86mm)	86HSPG80A460	4.5	6.0	4,5,10,16,20,25,40,50,100	JB860C
Planetary NEMA34(86mm)	86HSPG118A460	8.5	6.0	4,5,10,16,20,25,40,50,100	JB860C
Planetary NEMA34(86mm)	86HSPG156A460	12	6.0	4,5,10,16,20,25,40,50,100	JB860C
Worm NEMA23(57mm)	57HSWG41A430	0.6	3.0	5,7.5,10,15,20,25,30,40,50,60,80	JB542C
Worm NEMA23(57mm)	57HSWG51A430	1.0	3.0	5,7.5,10,15,20,25,30,40,50,60,80	JB542C
Worm NEMA23(57mm)	57HSWG56A430	1.3	3.0	5,7.5,10,15,20,25,30,40,50,60,80	JB542C
Worm NEMA23(57mm)	57HSWG76A440	2.3	3.0	5,7.5,10,15,20,25,30,40,50,60,80	JB542C
Worm NEMA23(57mm)	57HSWG85A440	2.6	3.0	5,7.5,10,15,20,25,30,40,50,60,80	JB542C
Worm NEMA23(57mm)	57HSWG115A440	3.5	3.0	5,7.5,10,15,20,25,30,40,50,60,80	JB542C
Worm NEMA34(86mm)	86HSWG65A442	3.3	4.2	5,7.5,10,15,20,25,30,40,50,60,80,100	JB860C
Worm NEMA34(86mm)	86HSWG80A460	4.5	6.0	5,7.5,10,15,20,25,30,40,50,60,80,100	JB860C
Worm NEMA34(86mm)	86HSWG118A460	8.5	6.0	5,7.5,10,15,20,25,30,40,50,60,80,100	JB860C
Worm NEMA34(86mm)	86HSWG156A460	12	6.0	5,7.5,10,15,20,25,30,40,50,60,80,100	JB860C
Right-angle Planetary NEMA17(42mm)	42HSZPG33A415	0.2	1.5	3,4,5,8,12,16,20,25,32,35,40,56,64	JB415M
Right-angle Planetary NEMA17(42mm)	42HSZPG38A415	0.4	1.5	3,4,5,8,12,16,20,25,32,35,40,56,64	JB415M
Right-angle Planetary NEMA17(42mm)	42HSZPG47A415	0.6	1.5	3,4,5,8,12,16,20,25,32,35,40,56,64	JB415M
Right-angle Planetary NEMA17(42mm)	42HSZPG60A415	0.8	1.5	3,4,5,8,12,16,20,25,32,35,40,56,64	JB415M
Right-angle Planetary NEMA23(57mm)	57HSZPG41A430	0.6	3.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB542C
Right-angle Planetary NEMA23(57mm)	57HSZPG51A430	1.0	3.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB542C
Right-angle Planetary NEMA23(57mm)	57HSZPG56A430	1.3	3.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB542C
Right-angle Planetary NEMA23(57mm)	57HSZPG76A440	2.3	4.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB542C
Right-angle Planetary NEMA23(57mm)	57HSZPG85A440	2.6	4.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB542C
Right-angle Planetary NEMA23(57mm)	57HSZPG115A440	3.5	4.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB542C
Right-angle Planetary NEMA34(86mm)	86HSZPG65A442	3.3	4.2	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB860C
Right-angle Planetary NEMA34(86mm)	86HSZPG80A460	4.5	6.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB860C
Right-angle Planetary NEMA34(86mm)	86HSZPG118A460	8.5	6.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB860C
Right-angle Planetary NEMA34(86mm)	86HSZPG156A460	12	6.0	3,4,5,7,10,12,16,20,25,28,35,40,50,70	JB860C
