Category

Product	Model	Voltage(VDC)	Power(W)	Motor Rated Torque(N.m)	Reduction Ratio
Planetary and Brake 42mm	J42BLSPGB40-240A	24	26	0.063	4,5,10,16,20,25,40,50,100
Planetary and Brake 42mm	J42BLSPGB60-240A	24	52	0.125	4,5,10,16,20,25,40,50,100
Planetary and Brake 42mm	J42BLSPGB80-240A	24	69	0.165	4,5,10,16,20,25,40,50,100
Planetary and Brake 42mm	J42BLSPGB100-240A	24	105	0.25	4,5,10,16,20,25,40,50,100
Planetary and Brake 57mm	J57BLSPGB55-230A	24	63	0.2	4,5,10,16,20,25,40,50,100
Planetary and Brake 57mm	J57BLSPGB75-230A	24	125	0.4	4,5,10,16,20,25,40,50,100
Planetary and Brake 57mm	J57BLSPGB95-230A	24	188	0.6	4,5,10,16,20,25,40,50,100
Planetary and Brake 60mm	J60BLSPGB99-430A	48	200	0.65	4,5,10,16,20,25,40,50,100
Planetary and Brake 60mm	J60BLSPGB120-430A	48	300	0.95	4,5,10,16,20,25,40,50,100
Planetary and Brake 60mm	J60BLSPGB140-430A	48	400	1.25	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB80-430A	48	314	1.0	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB105-430A	48	565	1.8	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB115-430A	48	659	2.1	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB130-430A	48	785	2.5	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB80-630A	310	314	1.0	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB105-630A	310	565	1.8	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB115-630A	310	659	2.1	4,5,10,16,20,25,40,50,100
Planetary and Brake 86mm	J86BLSPGB130-630A	310	785	2.5	4,5,10,16,20,25,40,50,100
Worm and Brake 57mm	J57BLSWGB55-230A	24	63	0.2	5,7.5,10,15,20,25,30,40,50
Worm and Brake 57mm	J57BLSWGB75-230A	24	125	0.4	5,7.5,10,15,20,25,30,40,50
Worm and Brake 57mm	J57BLSWGB95-230A	24	188	0.6	5,7.5,10,15,20,25,30,40,50
Worm and Brake 60mm	J60BLSWGB99-430A	48	200	0.65	5,7.5,10,15,20,25,30,40,50
Worm and Brake 60mm	J60BLSWGB120-430A	48	300	0.95	5,7.5,10,15,20,25,30,40,50
Worm and Brake 60mm	J60BLSWGB140-430A	48	400	1.25	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB80-430A	48	314	1.0	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB105-430A	48	565	1.8	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB115-430A	48	659	2.1	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB130-430A	48	785	2.5	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB80-630A	310	314	1.0	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB105-630A	310	565	1.8	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB115-630A	310	659	2.1	5,7.5,10,15,20,25,30,40,50
Worm and Brake 86mm	J86BLSWGB130-630A	310	785	2.5	5,7.5,10,15,20,25,30,40,50
Right-angle Planetary and Brake 42mm	J42BLSZPGB40-240A	24	26	0.063	3,4,5,8,12,16,20,25,32,40
Right-angle Planetary and Brake 42mm	J42BLSZPGB60-240A	24	52	0.125	3,4,5,8,12,16,20,25,32,40
Right-angle Planetary and Brake 42mm	J43BLSZPGB80-240A	24	69	0.165	3,4,5,8,12,16,20,25,32,40
Right-angle Planetary and Brake 42mm	J43BLSZPGB100-240A	24	105	0.25	3,4,5,8,12,16,20,25,32,40
Right-angle Planetary and Brake 57mm	J57BLSZPGB55-230A	24	63	0.2	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 57mm	J57BLSZPGB75-230A	24	125	0.4	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 57mm	J57BLSZPGB95-230A	24	188	0.6	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB80-430A	48	314	1.0	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB105-430A	48	565	1.8	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB115-430A	48	659	2.1	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB130-430A	48	785	2.5	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB80-630A	310	314	1.0	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB105-630A	310	565	1.8	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB115-630A	310	659	2.1	3,4,5,7,10,12,20,25,28,40,50
Right-angle Planetary and Brake 86mm	J86BLSZPGB130-630A	310	785	2.5	3,4,5,7,10,12,20,25,28,40,50
